Epoxy Oil Resistant Conductive Anti-static Top Coat

A two-component conductive topcoat made of epoxy resin, conductive additives, non-carbon conductive fillers, polyamide resin, etc.

向下滚动

Epoxy Oil Resistant Conductive Anti-static Top Coat Core functions

  • Excellent adhesion, impermeability,Good long-term electrical conductivity. -

  • Excellent resistance to acids, alkalis and salts and oil resistance. Excellent sealing properties.

Widely used in multiple industries
Provide solutions according to needs

Epoxy Oil Resistant Conductive Anti-static Top Coat Technical Parameter

  • Product Technical Parameters

  • Matching cleaning agents and diluents

  • Surface treatment and painting

Consulting Technology

Project

Performance indicator

Colour

Grey

Status in the container

No hard lumps after mixing and homogeneous

Constructability

Coating barrier-free

Film appearance

Flat and smooth

Gloss (60°)/°,

50

Fineness/μm,

50

Drying time/h,

Table dry

1.5

Actual drying

24

Non-volatile fraction/%,

75

Surface resistance

105 -109 Ω

Density, g/ml

1.5±0.05

VOC (Factory value),

220mg/L

Recommended dry film thickness

40-100µm

Theoretical coating rate (40µm)

0.09kg/

Application period (25°C)/h,

6


The ratio of the main agent and the curing agent is 8 : 1, and the epoxy diluent is added 10-15 %,

Steel surface treatment according to the national standard "steel surface rust grade and rust removal grade before painting" GB8923-88 implementation, sandblasting rust removal to achieve the national standard Sa2.5 grade, manual rust removal to achieve St3 grade.


Construction method

 The high-pressure airless spraying, brushing, and rolling are applied.
